We are selling a replacement 30A regulator 14V-3FHVSP-30A-AX-KS-LI for the Honda CBR 600 600F 900 1000 1100 motorcycle . The warranty is 4 years.



   Voltage regulator 14V-3FHVSP-30A-AX-KS-LI is a perfect replacement for the original Honda regulator. Namely, the original regulator on the Honda has a parallel type of regulation and as such loads the stator winding 100%. A cheaper parallel mosfet regulator may heat up less, but it maximally loads the stator winding of the generator, so it is advisable to choose a series type regulator that loads the generator only with consumption (which is always below 100% of the generator's power). This regulator also works well at high engine speeds. A double regulator regulates the voltage and protects the electronics from possible overvoltage. There are more arguments for using a serial regulator in the article.



   Battery voltage regulation is more than good. You can find more details about the regulator itself in the documentation: 14V-3FHVSP-30A-AX-KS-LI.pdf

   The new regulator probably does not fit in the same place and when replacing it, it is necessary to make an additional adjustment (make a different fixture and solve the connection of the wires to the installation). You must never mount the regulator where it is hit by water, stones and mud from the wheels or hot air. Filling the ribs of the regulator with dirt leads to its overheating, shutdown due to overheating, insufficient charging of the battery, and eventually to the failure of the battery and the regulator.



   The charging voltage should be from 14.1 to 14.3VDC. If a lower voltage is reached, it is necessary to solve the problem using the instructions. The minimum battery charging voltage that ensures a full battery is 13.9VDC. The regulator has a built-in LED that lights up in case the regulator failed to reach the required voltage on its connections.



   Warning: It is not allowed to wash the regulator with a high - pressure cleaner!
